MMR takes the 24' GT to Buttonwillow Raceway for the Speed Ventures Mustang Time Trial Challenge (competition for fastest lap)

We should start by saying that normal driving the car is just fine.

At the track however our base GT (that lacks a bumper mounted oil cooler like the darkhorse) overheated instantly on every lap. The Track is about 2 mins long, each session the car started the lap at normal operating temp and about 3/4 lap oil temp was in the red and the car is limited to 4500rpm (and possibly other ecu limiters).

Next issue is the clutch/transmission, again, normal driving is just fine, but at the track, the clutch pedal would stick to the floor at least once per lap and sometime would not come up but the car seemed to be in neutral (but wasnt) , this may be a throwout bearing issue or Ford has added some drivetrain protections.

We will have the overheating sorted out shortly and will offer the oil cooler kits later this week on the website in the 24' section. The clutch/trans issue might take some more time to figure out so stay tuned on that.

Our Mods so far:
MMR/MCS Coil Overs
MMR Adjustable Camber Plates
MMR Adjustable SwayBar End Links
Ford GT350R Extended front Studs
MMR Extended rear Studs
Currently on GT350R Carbon Fiber wheels

Stay Tuned for More Updates

Sep-17-2023-Speed Ventures (Sun) [[7e780ba612]] - Red - Session 3 (Off Ramp) - BW3_3369_Sep172...jpg


Sep-17-2023-Speed Ventures (Sun) [[7e780ba612]] - Red - Session 3 (Off Ramp) - BW3_3369_Sep172...jpg
Sponsored



Zig

Well-Known Member
Joined
Jul 21, 2023
Threads
15
Messages
1,058
Reaction score
521
Location
Virginia
Vehicle(s)
gt pp, Xt5 Sprt, c6 f55, 1500 z71, fatboy, sprtstr
‘ the clutch pedal would stick to the floor’ stick or pull itself down/in? What were the rpm’s at the time?

edit: or just overheating?

Last edited:

Zig

Well-Known Member
Joined
Jul 21, 2023
Threads
15
Messages
1,058
Reaction score
521
Location
Virginia
Vehicle(s)
gt pp, Xt5 Sprt, c6 f55, 1500 z71, fatboy, sprtstr
Why does 4500 sound familiar?

OP
OP
Mod Mustang Racing

Mod Mustang Racing

Well-Known Member
Diamond Sponsor
Joined
Oct 7, 2014
Threads
13
Messages
101
Reaction score
36
Location
California
Website
www.modularmotorsportsracing.com
Vehicle(s)
Worlds Fastest & Only 5 second Coyote
‘ the clutch pedal would stick to the floor’ stick or pull itself down/in? What were the rpm’s at the time?

edit: or just overheating?
Stick to the floor sometimes, other times it would come up but the car was still not engaged (acted like a missed gear but was not)

OP
OP
Mod Mustang Racing

Mod Mustang Racing

Well-Known Member
Diamond Sponsor
Joined
Oct 7, 2014
Threads
13
Messages
101
Reaction score
36
Location
California
Website
www.modularmotorsportsracing.com
Vehicle(s)
Worlds Fastest & Only 5 second Coyote
Why does 4500 sound familiar?
There are lots of RPM limiters depending on the failure, the 4500rpm was at a glance so dont hold us to that exactly but certainly right around that rpm. This seemed unrelated to the clutch issues.



FlyNavy86

Well-Known Member
Joined
Aug 9, 2023
Threads
8
Messages
74
Reaction score
73
Location
Memphis
Vehicle(s)
99 Gold Camry
Hmmm. I really want to track the GT, this might be a deal breaker for me if this is a widespread issue.

OP
OP
Mod Mustang Racing

Mod Mustang Racing

Well-Known Member
Diamond Sponsor
Joined
Oct 7, 2014
Threads
13
Messages
101
Reaction score
36
Location
California
Website
www.modularmotorsportsracing.com
Vehicle(s)
Worlds Fastest & Only 5 second Coyote
Hmmm. I really want to track the GT, this might be a deal breaker for me if this is a widespread issue.
We will have you covered on the oil cooler part , the clutch part is strange and concerning, we are doing more research on this to figure out what is happening.


RJV15

Well-Known Member
Joined
Apr 17, 2023
Threads
2
Messages
461
Reaction score
489
Location
Los Angeles
Vehicle(s)
2022 Honda Civic Si
There was a thread where a guys new GT wouldnt rev over 4500 RPM - manual transmission car as well
Pretty sure that guy was stuck in Limp Mode. Wonder if he took it in to the dealership.


Cody5.0

Active Member
Joined
Apr 30, 2019
Threads
3
Messages
34
Reaction score
13
Location
Nebraska
Vehicle(s)
2018 GT Performance Pack Level II
MMR takes the 24' GT to Buttonwillow Raceway for the Speed Ventures Mustang Time Trial Challenge (competition for fastest lap)

We should start by saying that normal driving the car is just fine.

At the track however our base GT (that lacks a bumper mounted oil cooler like the darkhorse) overheated instantly on every lap. The Track is about 2 mins long, each session the car started the lap at normal operating temp and about 3/4 lap oil temp was in the red and the car is limited to 4500rpm (and possibly other ecu limiters).

Next issue is the clutch/transmission, again, normal driving is just fine, but at the track, the clutch pedal would stick to the floor at least once per lap and sometime would not come up but the car seemed to be in neutral (but wasnt) , this may be a throwout bearing issue or Ford has added some drivetrain protections.

We will have the overheating sorted out shortly and will offer the oil cooler kits later this week on the website in the 24' section. The clutch/trans issue might take some more time to figure out so stay tuned on that.

Our Mods so far:
MMR/MCS Coil Overs
MMR Adjustable Camber Plates
MMR Adjustable SwayBar End Links
Ford GT350R Extended front Studs
MMR Extended rear Studs
Currently on GT350R Carbon Fiber wheels

Stay Tuned for More Updates

Sep-17-2023-Speed Ventures (Sun) [[7e780ba612]] - Red - Session 3 (Off Ramp) - BW3_3369_Sep172...jpg


Sep-17-2023-Speed Ventures (Sun) [[7e780ba612]] - Red - Session 3 (Off Ramp) - BW3_3369_Sep172...jpg
Wonder if the clutch issue has anything to do with the newly added pressure damper/restrictor in the line.

OP
OP
Mod Mustang Racing

Mod Mustang Racing

Well-Known Member
Diamond Sponsor
Joined
Oct 7, 2014
Threads
13
Messages
101
Reaction score
36
Location
California
Website
www.modularmotorsportsracing.com
Vehicle(s)
Worlds Fastest & Only 5 second Coyote
Wonder if the clutch issue has anything to do with the newly added pressure damper/restrictor in the line.
Something funny is going on, like we mentioned in some other threads , the car was in 4th gear, clutch pedal released and car acted like it was in neutral, which without ECU intervention we do not know how this can happen (other than clutch slippage which it definitely was not). Within the engine compartment the line going to the clutch looks business as usual, perhaps under the car or under the dash at the pedal there are other things going on?? It would make sense that there is a solenoid perhaps on the pressure line going to the throwout bearing, if closed while the clutch was depressed the pedal would stick to the floor - which it did numerous times.....


06mach1

Member
Joined
Aug 12, 2022
Threads
0
Messages
24
Reaction score
28
Location
NY
Vehicle(s)
2012 Boss 302LS
Is the clutch fluid reservoir and brake reservoir one in the same? Did you swap the fluid out to DOT4? You may be boiling the clutch fluid?


LETHAL

From the D but in the NC
Joined
Sep 25, 2015
Threads
12
Messages
1,493
Reaction score
796
Location
From the D to NC
Vehicle(s)
2024 Mustang GT
This is disappointing to read.

Thankfully, we have the aftermarket.


Stratman397

Well-Known Member
Joined
Jul 30, 2023
Threads
23
Messages
1,440
Reaction score
514
Location
Seneca,SC
Vehicle(s)
2018 jeep grand Cherokee, 2006 rubicon
Hmmm. I really want to track the GT, this might be a deal breaker for me if this is a widespread issue.
I have not had any clutch problems with mine. Of course, I don’t race it like that, but have started getting it moving a little more than I was. Getting it up to 4500 RPM’s now. Starting to feel the speed finally
